产品列表

产品中心 >> 电容 >> ATC

800R
FEATURES
• Case R Size (.070” x .090”) • Capable of highest RF Power
• Rugged, reliable NPO dielectric • RoHS Compliant / Lead-Free
• Optimized for highest self • Optimized for lowest ESR
resonant frequency and superior heat transfer
• Capacitance Range
1 pF to 100 pF
800e
FEATURES
• Case E Size (.380” x .380”)
• Capacitance Range 3.3 pF to 5100 pF
• Ultra Low ESR
• High Q
• High RF Power
• Ultra-Stable Performance
• High RF Current/Voltage
• High Reliability
700e
FEATURES
• Case E Size (.380” x .380”)
• Capacitance Range 1pF to 2200pF
• Extended WVDC up to 7200 VDC
• Low ESR/ESL
• High Q
• High RF Power
• Ultra-Stable Performance
• High RF Current/Voltage
• Available with Encapsulation Option*
* For leaded styles only
700b
Case B Size:(.110" x.110")
Capacitance Range: 0.1 pF to 5100 pF
Low ESR/ESL
Zero TCC
Low Noise
High Self-Resonance
Rugged Construction
Established Reliability (QPL)
Extended wvDC up to 1500 vDc
100e
FEATURES
• Case E Size (.380” x .380”)
• Capacitance Range 1pF to 5100pF
• Extended WVDC up to 7200 VDC
• Low ESR/ESL
• High Q
• High RF Power
• Ultra-Stable Performance
• High RF Current/Voltage
• Available with Encapsulation Option*
* For leaded styles only
100C
FEATURES
• Case C Size (.250" x .250")
• Capacitance Range 1pF to 2700pF
• Extended WVDC up to 3600 VDC
• Low ESR/ESL
• High Q
• Low Noise
• Ultra-Stable Performance
• High Self-Resonance
• Established Reliability (QPL)
